Features

·Support DALI-2+pushDIM mode
·level current output can be realized by DIP-switch
·Support EnergyData function and energy-reporting reading(DALIPart252)
·Support Luminaire data reading(DALIPart251),support diagnostics-maintenance reading(DALIPart253)
·Support advanced functions such as corridorDIM,EL,CLO
·The output current programming can be realized through the DALI interface
·Soft dimming and flicker-free at any brightness
·Using HPC patented technology, at any dimming level, the brightness of the lights is the same
·Standby power input<0.5W, meets the requirements of ErP certification
·High PF, high efficiency, low THD
·Optional Junction box: support up to 2.5mm2 cable and loop-through function
·Screw-free and pressing type strain relief, supports thicker cables and is easier to install
·Independent input and output strain relief, stronger wiring
·Intelligent LED hot-plug protection function
·SELV and Class II design, suitable for use outside or inside of the luminaires
·Passed CE,ENEC,UKCA,RCM,DALI-2 and other certifications
·IP20 protection grade, indoor use
·Nominal life-time up to 100,000 h
·5.5-year guarantee
