Dimmable driver

Dimmable driver

DGL(S) series

DALI DT8+pushDIM +pushCCT

EnergyData DALI Part(251~253), DALI&NFC programming, flicker-free,ZhagaBook 13 standards,40~80W

DAN series

DALI-2/pushDIM/Non-isolated

DALI-2+pushDIM dimming，corridorDIM,EL,CLO，DALI&NFC programmable,14/16-level current output,DIP-switch,1-100%,25-150W

DAL series

DALI DT6+pushDIM

DALI-2 DT6+pushDIM ,16-level current output, DIP-switch, 1-100%, Linear, SELV, Class I, CC and filcker-free output, 30~80W

DGL(E) series

DALI DT8+pushDIM +pushCCT

EnergyData DALI Part(251~253), DALI&NFC programming, flicker-free,ZhagaBook 13 standards,40W

DBL(E) series

DALI DT6+pushDIM

DALI-2+pushDIM,EnergyData function and energy-reporting reading,Luminaire data reading,diagnostics-maintenance reading,SELV,Class I,40W

DBL(S) series

DALI DT6+pushDIM

DALI-2+pushDIM,EnergyData, DALI part 251 252 253,SELV,Class I,DALI programmable, NFC programmable, SELV, Class l, 40~80W

CJL series

1-10V/PWM/12V

1-10V/10V PWM/Rx +12V aux power or PWM+12V aux power,10-level current output , DIP-switch, 1-100% , Linear, SELV, Class I, CC and filcker-free output, 30~80W

KHL series

Isolation 1-10V

1-10V/10V PWM/Rx, Isolated dimming interface, 10-level current output, DIP-switch, 5-100%, Linear , SELV, Class I, CC and filcker-free output, 30~80W

DAN(E) series

DALI-2/pushDIM/Non-isolated

Input andoutput non-isolated; EnergyDATA DALI Part 251~253; 13/15/16-level current output; DALI and NFC interface programming;25-150W

EML series

1-10V/10V

1-10V/10V PWM/Rx dimming,3.3V/5V/10V PWM dimming,12V 100mA auxiliary power,10-level current,DIP-switch,Any level Noise-free,0.04%Any level flicker-free,60-80W

MAN series

1-10V/10V PWM/Rx

1-10V/10V PWM/Rx,Soft dimming,flicker-free,10-level current output,Dimming range 1~100%,output current accuracy 5%,Class I,40-100W

PYN-B series

0-10V/10V PWM+12V

0-10V/10V PWM+12V,Inputand output non-isolated,Non-selv 12V power output,4-level current output,Auxiliary 12V supports fast power-down feature,42-60W

DWL(E) series

DALl DT8+pushDlM+pushCCT

Energy DATA(DALI Part 251-253),DALI programming,10-level current output,flicker-free,SELV,Class II,High PF, high efficiency, low THD,22~40W

PYN(S) series

0-10V/10V PWM+12V

Non-selv 12V power output,4-level current output,High PF, high efficiency, low THD,Class I,Zhaga Book 13，42~60W

PYN(E) series

3.3V/5V/10VPWM+12V

Inputand output non-isolated,4/8-level current output,flicker-free,High PF, high efficiency, low THD,Class I,Zhaga Book 13,22~80W

MEV series

1-10V/10V/12V

1-10V/10V PWM/Rx dimming+12v auxiliary power,1-100%,flicker-free,High PF,low THD,SELV,Class I,80-200W

DWV series

DALI DT8/pushDIM /pushCCT

DALI-2+pushDIM+pushCCT control,2 channels of constant voltage outpu,CV and flicker-free,1~100%,High PF,low THD,SELV,Class I,100-200w

DCV series

DALI-2+pushDIM+pushCCT

DALI-2+pushDIM+pushCCT control,flicker-free,1-100%,2 channels of constant voltage output,SELV,Class I,80-200W

DGV series

DALI DT6/pushDIM/1-10V+12V

DALI-2 DT6 +pushDIM+12v aux power, 1-100% , High PF, Linear, SELV, Class I or Class II, CV and filcker-free output, 60~150W , 24V/48V

DEV series

DALI-2/pushDIM+1-10V/10+12V

DALI-2/pushDIM+1-10V/10 PWM/Rx dimming+12V auxiliary power，flicker-free，1-100%，High PF，low THD，SELV，Class I，80-200W

DWL(S) series

DALI DT8/pushDIM /EnergyDATA/Dual input

Energy DATA(DALI Part 251-253),DALI programming,10-level current output,flicker-free,SELV,Class II,High PF, high efficiency, low THD,10~40W

DVL(S) series

DALl-2+pushDlM+pushCCT

EnergyDATA DALI Part 251~253; corridorDlM,EL,CLO; DALI programming; 16-level current output; loop-in and loop-out; 40W

MGV series

Isolation 1-10V/12V

1-10V/10V PWM/Rx +12V aux power , isolate interface dimming, 1-100% , High PF, Linear, SELV, Class I or Class II, CV and filcker-free output, 60~150W, 24V/48V

DFL series

DALI DT6/D4i/Dual input

DALI-2 DT6+DALI D4i dimming,EL,CLO,Loop-in and loop-out wiring,Built-in input AC and output DC power metering,Quickly install,16-level current output,DIP-switch,30~60W

DKL series

DALI-2+pushDIM

DALI-2,pushDIM,10-level current output,Soft dimming,flicker-free,Standby power input<0.5W,High PF, high efficiency, low THD,SELV,CLASS II,22-40W

DDL(E) series

DALI-2+pushDIM

DALI-2,pushDIM,EnergyDATAfunction and energy-reporting reading,support Luminaire data reading,supportdiagnostics-maintenance reading,40W

DUL series

DALI-2+pushDIM/10-10V

DALI-2+pushDIM+1-10V/10V,corridorDIM,EL,CLO,DALI&NFC programmable,10/16-level,DIP-switch,flicker-free,SELV,Class II,10-60W

DEL series

DALI DT6/pushDIM

DALI-2 DT6 + pushDIM, 16-level current output, external DIP-switch, 1-100%, Independent, SELV, Class II, CC and filcker-free output, 10-60W

DCL series

DALI DT6/pushDIM

DALI-2+pushDIM dimming,8-level DIP-switch,1~100%, High PF,Low THD,Independent input,SELV,Class II,Intelligent LED hot-plug,10W

DQL(S) series

DALI-2+pushDlM

EnergyDATA DALI Part 251~253; Optional Junction box; DALI programming; 16-level current output; loop-in and loop-out; 42W

WAL(E) series

XDIM dimming+12V

XDIM dimming+12V,Provide 12V 100mA auxiliary power supply to power control module or sensor,10-level current output,22-40W

KUL series

Isolation 1-10V

1-10V/10V PWM/Rx, Isolated dimming interface, 10-level current output, external DIP-switch, 5-100%, SELV, Class II, CC and filcker-free output, 30~60W

MUL series

Isolation 1-10V

1-10V/10V PWM/Rx, Isolated dimming interface, 10-level current output, external DIP-switch, 1-100%, Independent, Class II, CC and filcker-free output, 10-22W

DWT series

DC track light/DT8

DALI-2 DT8,DC48V track light,not affected by magnets,flick-free,Any brightnes is noise-free,good compatibility,SELV,Class III,12-30W

DET series

DALI Dt6/DC track light

CC Built-in,DC track light, DALI-2 DT6 dimming,No polarity of input,10-level current outpu,DIP-switch,CC and filcker-free output,0.1~100%,SELV,Class III,12-30W

DSL(S) series

DALI-2 DT8+pushDlM+pushCCT

EnergyDATA DALI Part 251~253; corridorDlM,EL,CLO; DALI programming; 16-level current output; 42W

DTL(S) series

DALI-2 DT6+pushDlM

EnergyDATA DALI Part 251~253; corridorDlM,EL,CLO; DALI programming; 16-level current output; 42W

MML series

1-10V/10V PWM/Rx

1-10V/10V PWM/Rx dimming,1-10V(DIM) interface,High PF, high efficiency, low THD,Power input on stand-by < 0.5 W,IP65,22-40W

DNL series

DALI DT6/pushDIM

DALI-2 DT6+pushDIM, pushDIM dimming，EL+CLO,1-100%,SELV,Class ||,CC and filcker-free output,High PF low THD,10-42W

DML-B series

DALI-2/CLO/IP65

DALI-2,Support advanced functions such as CLO,IP65,1%~100%,flicker-free,High PF, high efficiency, low THD,22W-150W

DMV series

DALI-2+pushDIM

DALI-2+pushDIM,High PF, high efficiency, low THD,Dimming range 1%~100%,Soft dimming,flicker-free,Power input on stand-by < 0.5 W,IP67,150W
