DMV Series
CC Waterproof dimmable driver(DALI-2+pushDIM)
Features
·Support DALI-2+pushDIM dimming mode
·High PF, high efficiency, low THD
·Dimming range 0.1%~100%
·Soft dimming and flicker-free at any brightness, meets the new requirements
of ErP certification
·Using HPC patented technology, at any dimming level, the brightness of
the lights is the same
·Aluminum metal housing design
·Power input on stand-by < 0.5 W,compatible with ERP.
·IP67 design for indoor or outdoor installation
·5.5-year guarantee
Parameters
Model | Input voltage | Output power | Output voltage | Output current | PF | Efficiency | THD | Ta | Tc | Dimension(mm) |
BK-DMV060-24V0D | 110-277VAC | 60W | 24VDC | 2.5A | 0.99 | 88% | 6.5% | 60℃ | 90℃ | L182*W56*H34 |
BK-DMV100-24V0D | 110-277VAC | 100W | 24VDC | 4.2A | 0.95 | 92% | 7% | 60℃ | 90℃ | L182*W56*H34 |
BK-DMV150-24V0D | 110-277VAC | 150W | 24VDC | 6.25A | 0.99 | 92.5% | 3% | 60℃ | 90℃ | L214*W68*H38 |
BK-DMV150-48V0D | 110-277VAC | 150W | 48VDC | 3.12A | 0.99 | 93.5% | 3% | 60℃ | 90℃ | L214*W68*H38 |
BK-DMV250-24V0D | 110-277VAC | 250W | 24VDC | 10.4A | 0.99 | 93.5% | 4% | 60℃ | 90℃ | L217*W89.5*H45.5 |
Suffix D：DALI-2+pushDIM
Specifications
Item | Parameter |
Rated input voltage | 110-277VAC / 200-300VDC |
Limited voltage | 100-305VAC / 180-315VDC |
Input votage shock | 380V |
Output type | SELV |
Output current accuracy | 5% |
Dimming range | 0.1-100% |
Power on time | <0.7s(AC start),<0.7s(DC start),<0.5s(AC/DC switchover),<0.5s(Turn off ) |
Standby power | <0.5W |
Surge | L-N:4KV,L-FG/N-FG:6KV |
Flicker-free | Pst LM=0.088, SVM=0.052 |
Operation temperature | -20°C-60°C |
Protection class | IP67 |
Life time | Normal 100,000 hours |
Warranty | 5.5 years |
Dimension(unit:mm)
Wiring diagram
