PHL-C series

CC waterproof driver



Features

·Output flick-free, meets the new requirements of ErP certification
·IP65 design for indoor installation
·High PF, high efficiency, low THD
·Withstand 380VAC high voltage short-time shock
·Startup time <0.5s
·Aluminum metal housing design
·SELV and Class I design, suitable for use inside of the light
·Passed CE,ENEC,UKCA,RCM,EL certifications
·Nominal life-time up to 100,000 h
·5.5-year guarantee

Parameters

Model

Input voltage

Output power

Output voltage

Output current

PF

Efficiency

THD

Ta

Tc

Dimension(mm)

BK-PHL022-C0600A

200-240VAC/DC

22.8W

28-42VDC

0.15-0.6A

0.98

87.5%

6.5%

60℃

90℃

L126*W41*H29

BK-PHL040-C1100A

200-240VAC/DC

42W

28-42VDC

0.5-1.1A

0.98

90%

5%

60℃

90℃

L126*W41*H29

Specifications

Item

Parameter

Rated input voltage

200-240VAC/200-240VDC

Limited voltage

180-264VAC/180-264VDC

Input votage shock

380V

Protection type

Class I

Output type

SELV

Output current accuracy

5%

Dimming range

N/A

Power on time

<0.5s(AC start),<0.5s(Turn off )

No load output voltage

N/A

Surge

L-N:2KV,L-FG/N-FG:4KV

Flicker-free

Flickering percent(IEEE 1789)=0.163%(100Hz),Pst LM = 0.000, SVM = 0.002

Operation temperature

-30-60℃

Protection class

IP65

Life time

Normal 100,000 hours

Warranty

5.5 years

Dimension(unit:mm)
