DBL(E)-AWB Series
Constant current linear dimmable driver
·Support DALI-2+pushDIM dimming interface
·3 levels of color temperature optional by sliding switch
·Support EnergyData function and energy-reporting reading (DALI Part 252)
·Support Luminaire data reading (DALI Part251), support diagnostics maintenance reading (DALI Part253)
·Support advanced functions such as corridorDIM, CLO
·The output current and related parameters of the driver programming can be realized through the DALI interface
·Multi-level current output can be realized by DIP-switch
·Soft dimming and flicker-free at any brightness, meets the new requirements of ErP certification
·Using HPC patented technology at any dimming level, the brightness between lights is same
·High PF, high efficiency, low THD
·Intelligent LED hot-plug protection function
·Class design, suitable for use inside of the light
·Compliance with Zhaga Book 13 standards
·5.5-year guarantee
Parameters
Model | Input voltage | Output power | Output voltage | Output current | PF | Efficiency | THD | Ta | Tc | Dimension(mm) |
BK-DBL040E-AWB1050ADPC | 110-277VAC | 40W | 24-42VDC | 0.3-1.05A | 0.99 | 85.5% | 4% | 60℃ | 90℃ | L280*W30*H22.5 |
BK-DBL080E-AWB2000ADPC | 110-277VAC | 80W | 24-42VDC | 1.1-2A | 0.99 | 88.5% | 4% | 60℃ | 80℃ | L360*W30*H22.5 |
Suffix DP：DALI-2+pushDIM+EnergyData+CLO+corridorDIM+DALI programmable+CCT switch
Specifications
Item | Parameter |
Rated input voltage | 110-277VAC |
Limited voltage | 100-305VAC |
Input votage shock | 380V |
Protection type | Class || |
Output type | SELV |
Voltage accuracy | ±5% |
Dimming range | 1%-100% |
Power on time | <0.75s(AC start),<0.3s(AC switchover),<0.5s(Turn off ) |
Surge | L-N:2KV,L-G/N-G:4KV(Performance criterion:B) |
Flicker-free | Pst LM <1,SVM <0.4 |
Operation temperature | -25-60℃ |
Protection class | IP20 |
Life time | Normal 100,000 hours |
Warranty | 5.5 years |
Dimension(unit:mm)
Wiring diagram
