PBL(E)-A series
Constant current independent driver
Features
·7/11-level current output can be realized by DlP-switch
·Flicker-free output,which meets the requirement of ErP standard
·Two-stage and isolation,more stable and safer
·Dual input terminal design, Support loop-in and loop-out wiring without junction box
·Optional Junction Box: Support up to 2.5mm² Cable and Loop-through Function
·Withstand 380VAC high voltage short-time shock
·Mains surge capability up to 2KV
·Screw-free design,easy wiring
·High PF, low THD
·Pushable strain relief design,easy to crimp and install
·Compact housing design
·SELV and Class ll design, suitable for use outside of the light
·Passed CE,ENEC,UKCA,RCM,CCC and other certifications
·Nominal life-time up to 100,000 h
·5.5-year guarantee

Parameters
Model | Input voltage | Output power | Output voltage | Output current | PF | Efficiency | THD | Ta | Tc | Dimension(mm) |
BK-PBL022E-A0450AS | 200-240VAC | 18.9W | 28-42V | 0.2-0.45A | 0.98 | 87.5% | 9.5% | 50℃ | 80℃ | L123*W46*H30 |
BK-PBL022E-A0600AS | 200-240VAC | 25.2W | 28-42V | 0.3-0.6A | 0.98 | 89% | 8% | 50℃ | 80℃ | L123*W46*H30 |
BK-PBL022E-A0600ASE | 200-240VAC | 25.2W | 28-42V | 0.3-0.6A | 0.97 | 88% | 9% | 50℃ | 80℃ | L123*W46*H30 |
BK-PBL040E-A0900AS | 200-240VAC | 37.8W | 28-42V | 0.4-0.9A | 0.98 | 89.8% | 7.5% | 45℃ | 80℃ | L123*W46*H30 |
BK-PBL040E-A1000AS | 200-240VAC | 40W | 28-42V | 0.5-1A | 0.98 | 90% | 7% | 45℃ | 80℃ | L123*W46*H30 |
BK-PBL040E-A1000ASE | 200-240VAC | 40W | 28-42V | 0.5-1A | 0.97 | 89% | 8% | 45℃ | 80℃ | L123*W46*H30 |
Specifications
Item | Parameter |
Rated input voltage | 200-240VAC 200-240VDC |
Limited voltage | 180-264VAC/200-264VDC |
Input votage shock | 380V |
Protection type | Class || |
Output type | SELV |
No load output voltage | 54VDC |
Output current accuracy | 5% |
Standby power | <0.5W |
Surge | L-N:2KV |
Flicker-free | Pst LM <1,SVM <0.4 |
Operation temperature | -20-50℃ |
Protection class | IP20 |
Life time | Normal 100,000 hours |
Warranty | 5.5 years |
Dimension(unit:mm)

Wiring diagram
