BPL(S) series
CC independent driver
Features
·16-level current output can be realized by DlP-switch
·Flicker-free output,which meets the requirement of ErP standard
·With stand 380VAC high voltage short-time shock
·Mains surge capability up to 2KV
·High PF,high efficiency,low THD
·Compact housing design
·SELV and Class ll design,suitable foruse outside orinside ofthe light
·Compliance with CE,ENEC,UKCA,RCM,CCC,EL and other certifications
·lP20 protection grade,indo or use
·Nominal life-time up to 100,000 h
·5-year guarantee
Parameters
Model | Input voltage | Output power | Output voltage | Output current | PF | Efficiency | THD | Ta | Tc | Dimension(mm) |
BK-BPL040S-AHC1050AS | 200-240VAC/DC | 40W | 3-49VDC | 0.3-1.05A | 0.98 | 91% | 8% | 60℃ | 90℃ | L145.5*W30*H21.4mm(Built-in) |
BK-BPL036S-AHC0900AN | 200-240VAC/DC | 36W | 6-50VDC | 0.1-0.9A | 0.98 | 90% | 10% | 50℃ | 90℃ | L145.5*W30*H21.4mm(Built-in) |
Suffix N：NFC programmable
Suffix S：16 -level current output can be realized by DIP-switch
Specifications
Item | Parameter |
Rated input voltage | 200-240VAC/VDC |
Limited voltage | 180-264VAC/VDC |
Input votage shock | 380V |
Protection type | Class || |
Output type | SELV |
Voltage accuracy | 5% |
Dimming range | N/A |
Power on time | <0.5s |
Surge | |
Flicker-free | Pst LM =0.72,SVM =0.011, |
Operation temperature | -20-50℃ |
Protection class | IP20 |
Life time | Normal 100,000 hours |
Warranty | 5 years |
Dimension(unit:mm)
Wiring diagram
