DWL(S)-A Series
CC independent color temperature driver
Features
·Support DALI-2+pushDlM+pushCCT mode
·Support Energy DATA function and energy-reporting reading(DALI Part252)
·Support Luminaire data reading(DALiPart251),support diagnostics-maintenance reading(DALIPart253)
·Support advanced functions such as corridorDlM,EL,CLO
·The output current programming can be realized through the DALl interface
·8/16-level current output can be realized by DIP-switch
·Soft dimming and flicker-free at any brightness, meets the new requirements of ErP certification
·Using HPC patented technology, at any dimming level, the brightness of the lights is the same
·Standby power input<0.5W, meets the requirements of ErP certification
·High PF, high efficiency, low THD
·Screw-freeand pressing type strain relief, supports thicker cables and is easier toinstall
·Independent input and output strain relief,stronger wiring
·Intelligent LED hot-plug protection function
·SELV and Class ll design, suitable for use outside of the light
·Compliance with CE,ENEC,UKCA,RCM,CCC,DALl-2 and other certifications
·IP20 protection grade, in door use
·Nominal life time up to 100,000 h
·5.5-year guarantee
Parameters
Model | Input voltage | Output power | Output voltage | Output current | PF | Efficiency | THD | Ta | Tc | Dimension(mm) |
BK-DWL010S-A0350ADP | 200-240VAC | 10.8W | 9-54V | 0.1-0.35A | 0.96 | 84.5% | 9% | 50℃ | 90℃ | L111*W35*H20 |
BK-DWL040S-A1050ADP | 200-240VAC | 40W | 6-54V | 0.3-1.05A | 0.99 | 90% | 7% | 45℃ | 90℃ | L137*W46*H30 |
Specifications
Item | Parameter |
Rated voltage | 200-240VAC/200-240VDC |
Limited voltage | 180-264VAC 200-264VDC |
Overoltage protection | 380V |
Protection class | Class II,SELV |
Output current accuracy | 1% |
Dimming range | 0.1-100% |
Power on time | <0.5s |
Standby power | <0.5W |
No-load voltage | <59V |
Surge | L-N:2KV,L/N-FG:2KV |
Flicker-free | -25-45℃ |
IP rating | IP20 |
Life time | Normal 100000 hours |
Warranty | 5.5 years |
Dimension(unit:mm)
Wiring diagram
